Galil 6-AW 6.5-Inch, 2-Way On-Wall Outdoor Speakers
-
The Galil 6˙AW on˙wall outdoor speaker features a multi˙tap power transformer for selecting 8ž (bypassing the transformer) or 70V/100V power settings, which are suitable for an array installation. Suitable for outdoor installations and applications. Available in white or black.
- IP 66 Certified � Withstands heavy showers and other outdoor conditions.
- Type � 2-way on-wall speaker.
- Woofer � 6.5� polypropylene cone.
- Tweeter � 1� silk dome.
- Impedance � 8Ω.
- Power Handling � 40W RMS, 110W continuous program.
- Transformer Taps � 70V: 30W/15W/7.5W/3.7W/Off (Lo-Z); 100V: 30W/15W/7.5W/Off (Lo-Z).
- Package Includes � 2 speakers (1 pair), u-mount brackets, grommets.
- Colors Available � Black and white.
-
DESCRIPTION 2-way on-wall speakers
FREQUENCY RESPONSE 65Hz to 20kHz @-10dB, 80Hz to 20kHz @±3dB
WOOFER 6.5� (165mm) polypropylene cone with rubber surround
TWEETER 1� (25mm) silk dome
IMPEDANCE 8ž (transformer tap in off position)
TRANSFORMER TAPS 70V � 30W/15W/7.5W/3.7W/Off (Lo-Z), 100V � 30W/15W/7.5W/Off (Lo-Z)
SENSITIVITY 87dB SPL, 1W @1m
MAX SPL Continuous: 102dB, peak: 105dB
POWER HANDLING 40W RMS, 110W continuous program
CROSSOVER FREQUENCY 4.3kHz
DIRECTIVITY FACTOR (Q) 3.9 averaged 1kHz to 10kHz
DIRECTIVITY INDEX (DI) 5.9dB averaged 1kHz to 10kHz
INPUT CONNECTORS Terminal blocks
MATERIALS Frame, aluminum grill, steel brackets and ABS cabinet
STANDARDS COMPLIANCE IP66 compliant
OPERATING TEMPERATURE 0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE -40° to +70°C (-40° to 158°F)
HUMIDITY 10% to 90%, RHL non-condensing
WEIGHT PER SINGLE SPEAKER 2.8kg (6.2lbs) approx
WEIGHT WITH MOUNTING KIT 3kg (6.6lbs) approx
SHIPPING WEIGHT (FOR PAIR) 6.6kg (14.6lbs) approx
DIMENSIONS WITH MOUNTING BRACKETS 21.5cm x 22.5cm x 30.1cm (8.5� x 8.9� x 11.9�), W, D, H
INSTALLATION CLEARANCE Front panel to wall (with mounting bracket): 22.7cm (8.9�), back panel to wall (with mounting bracket): 3.8cm (1.5�)
ACCESSORIES 2 mounting brackets (including 4 knobs and 4 mounting screws)
OPTIONS BCP-2S speaker cable
COLORS Available in white or black
